利用Dyson方程迭代方法计算态密度(附Python代码)

在计算电导时,我们只需要知道格林函数右上角的一个分块矩阵G_{1n}。在计算态密度公式中,我们需要知道格林函数对角线上的元素,因此需要计算出格林函数所有的对角分块矩阵G_{11}G_{22}G_{33}……

本篇用上Dyson方程,计算格林函数的对角分块矩阵,进而计算出态密度。考虑的体系是有限长宽的方格子。用上Dyson方程后计算的矩阵维度可以大幅度降低,矩阵维度从width*length下降到width。

此外也可以参考这几篇:

戴森方程(Dyson equation) 为[1]:

计算G_{1n}具体公式可以写为:

\begin{aligned}G_{11}^{(1)}&=[(E+i\eta)I-H_{11}]^{-1}\\G_{12}^{(2)}&=G_{11}^{(1)}V_{12}G_{22}^{(2)}\\G_{13}^{(3)}&=G_{12}^{(2)}V_{23}G_{33}^{(3)}\\&\quad\quad......\end{aligned}

其中,

\begin{aligned}G_{22}^{(2)}&=[(E+i\eta)I-H_{22}-V_{12}^{\dagger}G_{11}^{(1)}V_{12}]^{-1}\\G_{33}^{(3)}&=[(E+i\eta)I-H_{33}-V_{23}^{\dagger}G_{22}^{(2)}V_{23}]^{-1}\\&\quad\quad\quad\quad\quad\quad......\end{aligned}

通常,H_{11}=H_{22}=H_{33}V_{12}=V_{23}

此外,如果考虑了左电极的自能\Sigma_{L},则G_{11}^{(1)}=[(E+i\eta)I-H_{11}-\Sigma_{L}]^{-1}

需要说明的是:格林函数G^{(x)}的右上角括号(x)表示当前的体系大小。因此,这里的G_{11}^{(1)}G_{22}^{(2)}G_{33}^{(3)}……不是计算态密度所需要的对角分块矩阵。我们需要的是G_{11}^{(n)}G_{22}^{(n)}G_{33}^{(n)}……其中,(n)表示需要计算的体系大小。

下面给出具体的表达式:

\begin{aligned}G_{11}^{(1)}&=[(E+i\eta)I-H_{11}]^{-1}\\G_{11}^{(2)}&=G_{11}^{(1)}+G_{11}^{(1)}V_{12}G_{22}^{(2)}V_{12}^{\dagger}G_{11}^{(1)}\\G_{11}^{(3)}&=G_{11}^{(2)}+G_{12}^{(2)}V_{23}G_{33}^{(3)}V_{23}^{\dagger}G_{21}^{(2)}\\G_{11}^{(4)}&=G_{11}^{(3)}+G_{13}^{(3)}V_{34}G_{44}^{(4)}V_{34}^{\dagger}G_{31}^{(3)}\\&\quad\quad\quad\quad......\end{aligned}

\begin{aligned}G_{22}^{(2)}&=[(E+i\eta)I-H_{22}-V_{12}^{\dagger}G_{11}^{(1)}V_{12}]^{-1}\\G_{22}^{(3)}&=G_{22}^{(2)}+G_{22}^{(2)}V_{23}G_{33}^{(3)}V_{23}^{\dagger}G_{22}^{(2)}\\G_{22}^{(4)}&=G_{22}^{(3)}+G_{23}^{(3)}V_{34}G_{44}^{(4)}V_{34}^{\dagger}G_{32}^{(3)}\\G_{22}^{(5)}&=G_{22}^{(4)}+G_{24}^{(4)}V_{45}G_{55}^{(5)}V_{45}^{\dagger}G_{42}^{(3)}\\&\quad\quad\quad\quad\quad......\end{aligned}

其中,

\begin{aligned}G_{21}^{(2)}&=G_{22}^{(2)}V_{12}^{\dagger}G_{11}^{(1)}\\G_{31}^{(3)}&=G_{33}^{(3)}V_{23}^{\dagger}G_{21}^{(2)}\\&\quad......\end{aligned}

\begin{aligned}G_{23}^{(3)}&=G_{22}^{(2)}V_{23}G_{33}^{(3)}\\G_{24}^{(4)}&=G_{23}^{(3)}V_{34}G_{44}^{(4)}\\&\quad......\end{aligned}

\begin{aligned}G_{32}^{(3)}&=G_{33}^{(3)}V_{23}^{\dagger}G_{22}^{(2)}\\G_{42}^{(4)}&=G_{44}^{(4)}V_{34}^{\dagger}G_{32}^{(3)}\\&\quad......\end{aligned}

同理有G_{33}^{(n)}G_{44}^{(n)}G_{55}^{(n)}等。上面的表达式看起来虽然复杂,但都只是在套用Dyson方程的表达式。

补充说明:还有另外一种更加简单的算法(由zhangjiayan同学提供),是把每一层左右两侧都当成自能,参考书籍“2016 - Ryndyk - Theory of Quantum Transport at Nanoscale”。

1. 方格子

Python代码如下:

"""
This code is supported by the website: https://www.guanjihuan.com
The newest version of this code is on the web page: https://www.guanjihuan.com/archives/7650
"""

import numpy as np
import matplotlib.pyplot as plt
from math import *


def matrix_00(width):
    h00 = np.zeros((width, width))
    for width0 in range(width-1):
        h00[width0, width0+1] = 1
        h00[width0+1, width0] = 1
    return h00


def matrix_01(width):
    h01 = np.identity(width)
    return h01


def main():
    width = 2
    length = 3
    eta = 1e-2
    E = 0
    h00 = matrix_00(width)
    h01 = matrix_01(width)
    G_ii_n_array = G_ii_n_with_Dyson_equation(width, length, E, eta, h00, h01)
    for i0 in range(length):
        # print('G_{'+str(i0+1)+','+str(i0+1)+'}^{('+str(length)+')}:')
        # print(G_ii_n_array[i0, :, :],'\n')
        print('x=', i0+1, ':')
        for j0 in range(width):
            print('     y=', j0+1, ' ', -np.imag(G_ii_n_array[i0, j0, j0])/pi)   # 态密度


def G_ii_n_with_Dyson_equation(width, length, E, eta, h00, h01):
    G_ii_n_array = np.zeros((length, width, width), complex)
    G_11_1 = np.linalg.inv((E+eta*1j)*np.identity(width)-h00)
    for i in range(length):  # i为格林函数的右下指标
        # 初始化开始
        G_nn_n_minus = G_11_1
        G_in_n_minus = G_11_1
        G_ni_n_minus = G_11_1
        G_ii_n_minus = G_11_1
        for i0 in range(i):
            G_nn_n = Green_nn_n(E, eta, h00, h01, G_nn_n_minus)
            G_nn_n_minus = G_nn_n
        if i!=0:
            G_in_n_minus = G_nn_n
            G_ni_n_minus = G_nn_n
            G_ii_n_minus = G_nn_n
        # 初始化结束
        for j0 in range(length-1-i): # j0为格林函数的右上指标,表示当前体系大小,即G^{(j0)}
            G_nn_n = Green_nn_n(E, eta, h00, h01, G_nn_n_minus)
            G_nn_n_minus = G_nn_n

            G_ii_n = Green_ii_n(G_ii_n_minus, G_in_n_minus, h01, G_nn_n, G_ni_n_minus)  # 需要求的对角分块矩阵
            G_ii_n_minus = G_ii_n

            G_in_n = Green_in_n(G_in_n_minus, h01, G_nn_n)
            G_in_n_minus = G_in_n

            G_ni_n = Green_ni_n(G_nn_n, h01, G_ni_n_minus)
            G_ni_n_minus = G_ni_n
        G_ii_n_array[i, :, :] = G_ii_n_minus
    return G_ii_n_array


def Green_nn_n(E, eta, H00, V, G_nn_n_minus): # n>=2
    dim  = H00.shape[0]
    G_nn_n = np.linalg.inv((E+eta*1j)*np.identity(dim)-H00-np.dot(np.dot(V.transpose().conj(), G_nn_n_minus), V))
    return G_nn_n


def Green_in_n(G_in_n_minus, V, G_nn_n):  # n>=2
    G_in_n = np.dot(np.dot(G_in_n_minus, V), G_nn_n)
    return G_in_n


def Green_ni_n(G_nn_n, V, G_ni_n_minus): # n>=2
    G_ni_n = np.dot(np.dot(G_nn_n, V.transpose().conj()), G_ni_n_minus)
    return G_ni_n


def Green_ii_n(G_ii_n_minus, G_in_n_minus, V, G_nn_n, G_ni_n_minus):  # n>=i
    G_ii_n = G_ii_n_minus+np.dot(np.dot(np.dot(np.dot(G_in_n_minus, V), G_nn_n), V.transpose().conj()),G_ni_n_minus)
    return G_ii_n


if __name__ == '__main__':
    main()

计算结果为:

为了验证以上代码和计算结果的正确性,下面用传统直接求逆的方法计算态密度。计算的体系也是方格子。代码如下:

"""
This code is supported by the website: https://www.guanjihuan.com
The newest version of this code is on the web page: https://www.guanjihuan.com/archives/7650
"""

import numpy as np
import matplotlib.pyplot as plt
from math import *


def hamiltonian(width, length):
    h = np.zeros((width*length, width*length))
    for i0 in range(length):
        for j0 in range(width-1):
            h[i0*width+j0, i0*width+j0+1] = 1
            h[i0*width+j0+1, i0*width+j0] = 1
    for i0 in range(length-1):
        for j0 in range(width):
            h[i0*width+j0, (i0+1)*width+j0] = 1
            h[(i0+1)*width+j0, i0*width+j0] = 1
    return h


def main():
    width = 2
    length = 3
    h = hamiltonian(width, length)
    E = 0
    green = np.linalg.inv((E+1e-2j)*np.eye(width*length)-h)
    for i0 in range(length):
        # print('G_{'+str(i0+1)+','+str(i0+1)+'}^{('+str(length)+')}:')
        # print(green[i0*width+0: i0*width+width, i0*width+0: i0*width+width], '\n')
        print('x=', i0+1, ':')
        for j0 in range(width):
            print('     y=', j0+1, ' ', -np.imag(green[i0*width+j0, i0*width+j0])/pi)


if __name__ == "__main__":
    main()

计算结果为:

结果在误差范围内是相等的。

2. 立方格子

把每一层切片当成一个单元,进行Dyson方程的迭代。代码为:

"""
This code is supported by the website: https://www.guanjihuan.com
The newest version of this code is on the web page: https://www.guanjihuan.com/archives/7650
"""

import numpy as np
import matplotlib.pyplot as plt
from math import *


def matrix_00(width, length):
    h00 = np.zeros((width*length, width*length))
    for x in range(length):
        for y in range(width-1):
            h00[x*width+y, x*width+y+1] = 1
            h00[x*width+y+1, x*width+y] = 1
    for x in range(length-1):
        for y in range(width):
            h00[x*width+y, (x+1)*width+y] = 1
            h00[(x+1)*width+y, x*width+y] = 1
    return h00


def matrix_01(width, length):
    h01 = np.identity(width*length)
    return h01


def main():
    height = 2  # z
    width = 3   # y
    length = 4  # x
    eta = 1e-2
    E = 0
    h00 = matrix_00(width, length)
    h01 = matrix_01(width, length)
    G_ii_n_array = G_ii_n_with_Dyson_equation(width, length, height, E, eta, h00, h01)
    for i0 in range(height):
        print('z=', i0+1, ':')
        for j0 in range(width):
            print('      y=', j0+1, ':')
            for k0 in range(length):
                print('             x=', k0+1, ' ', -np.imag(G_ii_n_array[i0, k0*width+j0, k0*width+j0])/pi)   # 态密度


def G_ii_n_with_Dyson_equation(width, length, height, E, eta, h00, h01):
    dim = length*width
    G_ii_n_array = np.zeros((height, dim, dim), dtype=complex)
    G_11_1 = np.linalg.inv((E+eta*1j)*np.identity(dim)-h00)
    for i in range(height):  # i为格林函数的右下指标
        # 初始化开始
        G_nn_n_minus = G_11_1
        G_in_n_minus = G_11_1
        G_ni_n_minus = G_11_1
        G_ii_n_minus = G_11_1
        for i0 in range(i):
            G_nn_n = Green_nn_n(E, eta, h00, h01, G_nn_n_minus)
            G_nn_n_minus = G_nn_n
        if i!=0:
            G_in_n_minus = G_nn_n
            G_ni_n_minus = G_nn_n
            G_ii_n_minus = G_nn_n
        # 初始化结束
        for j0 in range(height-1-i): # j0为格林函数的右上指标,表示当前体系大小,即G^{(j0)}
            G_nn_n = Green_nn_n(E, eta, h00, h01, G_nn_n_minus)
            G_nn_n_minus = G_nn_n

            G_ii_n = Green_ii_n(G_ii_n_minus, G_in_n_minus, h01, G_nn_n, G_ni_n_minus)  # 需要求的对角分块矩阵
            G_ii_n_minus = G_ii_n

            G_in_n = Green_in_n(G_in_n_minus, h01, G_nn_n)
            G_in_n_minus = G_in_n

            G_ni_n = Green_ni_n(G_nn_n, h01, G_ni_n_minus)
            G_ni_n_minus = G_ni_n
        G_ii_n_array[i, :, :] = G_ii_n_minus
    return G_ii_n_array


def Green_nn_n(E, eta, H00, V, G_nn_n_minus): # n>=2
    dim  = H00.shape[0]
    G_nn_n = np.linalg.inv((E+eta*1j)*np.identity(dim)-H00-np.dot(np.dot(V.transpose().conj(), G_nn_n_minus), V))
    return G_nn_n


def Green_in_n(G_in_n_minus, V, G_nn_n):  # n>=2
    G_in_n = np.dot(np.dot(G_in_n_minus, V), G_nn_n)
    return G_in_n


def Green_ni_n(G_nn_n, V, G_ni_n_minus): # n>=2
    G_ni_n = np.dot(np.dot(G_nn_n, V.transpose().conj()), G_ni_n_minus)
    return G_ni_n


def Green_ii_n(G_ii_n_minus, G_in_n_minus, V, G_nn_n, G_ni_n_minus):  # n>=i
    G_ii_n = G_ii_n_minus+np.dot(np.dot(np.dot(np.dot(G_in_n_minus, V), G_nn_n), V.transpose().conj()),G_ni_n_minus)
    return G_ii_n


if __name__ == '__main__':
    main()

计算结果为:

用传统直接求逆的方法计算态密度进行验证,代码为:

"""
This code is supported by the website: https://www.guanjihuan.com
The newest version of this code is on the web page: https://www.guanjihuan.com/archives/7650
"""

import numpy as np
import matplotlib.pyplot as plt
from math import *


def hamiltonian(width, length, height):
    h = np.zeros((width*length*height, width*length*height))
    for i0 in range(length):
        for j0 in range(width):
            for k0 in range(height-1):
                h[k0*width*length+i0*width+j0, (k0+1)*width*length+i0*width+j0] = 1
                h[(k0+1)*width*length+i0*width+j0, k0*width*length+i0*width+j0] = 1
    for i0 in range(length):
        for j0 in range(width-1):
            for k0 in range(height):
                h[k0*width*length+i0*width+j0, k0*width*length+i0*width+j0+1] = 1
                h[k0*width*length+i0*width+j0+1, k0*width*length+i0*width+j0] = 1
    for i0 in range(length-1):
        for j0 in range(width):
            for k0 in range(height):
                h[k0*width*length+i0*width+j0, k0*width*length+(i0+1)*width+j0] = 1
                h[k0*width*length+(i0+1)*width+j0, k0*width*length+i0*width+j0] = 1
    return h


def main():
    height = 2  # z
    width = 3  # y
    length = 4  # x
    h = hamiltonian(width, length, height)
    E = 0
    green = np.linalg.inv((E+1e-2j)*np.eye(width*length*height)-h)
    for k0 in range(height):
        print('z=', k0+1, ':')
        for j0 in range(width):
            print('      y=', j0+1, ':')
            for i0 in range(length):
                print('             x=', i0+1, ' ', -np.imag(green[k0*width*length+i0*width+j0, k0*width*length+i0*width+j0])/pi)   # 态密度


if __name__ == "__main__":
    main()

计算结果为:

结果在误差范围内是一致的。

另外,下面把利用Dyson方程迭代方法计算态密度(立方格子)的代码做了一些细节上的修改,称为第二版本“version II"。主要是删除G_ii_n_array这个变量,因为这个变量太占内存了。经过处理后,在有限的内存下,能够计算的体系大小会更大一些,消耗的内存降低为1/height倍的量级。

"""
This code is supported by the website: https://www.guanjihuan.com
The newest version of this code is on the web page: https://www.guanjihuan.com/archives/7650
"""

import numpy as np
import matplotlib.pyplot as plt
from math import *


def matrix_00(width, length):
    h00 = np.zeros((width*length, width*length))
    for x in range(length):
        for y in range(width-1):
            h00[x*width+y, x*width+y+1] = 1
            h00[x*width+y+1, x*width+y] = 1
    for x in range(length-1):
        for y in range(width):
            h00[x*width+y, (x+1)*width+y] = 1
            h00[(x+1)*width+y, x*width+y] = 1
    return h00


def matrix_01(width, length):
    h01 = np.identity(width*length)
    return h01


def main():
    height = 2  # z
    width = 3   # y
    length = 4  # x
    eta = 1e-2
    E = 0
    h00 = matrix_00(width, length)
    h01 = matrix_01(width, length)
    G_ii_n_with_Dyson_equation_version_II(width, length, height, E, eta, h00, h01)


def G_ii_n_with_Dyson_equation_version_II(width, length, height, E, eta, h00, h01):
    dim = length*width
    G_11_1 = np.linalg.inv((E+eta*1j)*np.identity(dim)-h00)
    for i in range(height):  # i为格林函数的右下指标
        # 初始化开始
        G_nn_n_minus = G_11_1
        G_in_n_minus = G_11_1
        G_ni_n_minus = G_11_1
        G_ii_n_minus = G_11_1
        for i0 in range(i):
            G_nn_n = Green_nn_n(E, eta, h00, h01, G_nn_n_minus)
            G_nn_n_minus = G_nn_n
        if i!=0:
            G_in_n_minus = G_nn_n
            G_ni_n_minus = G_nn_n
            G_ii_n_minus = G_nn_n
        # 初始化结束
        for j0 in range(height-1-i): # j0为格林函数的右上指标,表示当前体系大小,即G^{(j0)}
            G_nn_n = Green_nn_n(E, eta, h00, h01, G_nn_n_minus)
            G_nn_n_minus = G_nn_n

            G_ii_n = Green_ii_n(G_ii_n_minus, G_in_n_minus, h01, G_nn_n, G_ni_n_minus)  # 需要求的对角分块矩阵
            G_ii_n_minus = G_ii_n

            G_in_n = Green_in_n(G_in_n_minus, h01, G_nn_n)
            G_in_n_minus = G_in_n

            G_ni_n = Green_ni_n(G_nn_n, h01, G_ni_n_minus)
            G_ni_n_minus = G_ni_n
        # 输出
        print('z=', i+1, ':')
        for j0 in range(width):
            print('      y=', j0+1, ':')
            for k0 in range(length):
                print('             x=', k0+1, ' ', -np.imag(G_ii_n_minus[k0*width+j0, k0*width+j0])/pi)   # 态密度


def Green_nn_n(E, eta, H00, V, G_nn_n_minus): # n>=2
    dim  = H00.shape[0]
    G_nn_n = np.linalg.inv((E+eta*1j)*np.identity(dim)-H00-np.dot(np.dot(V.transpose().conj(), G_nn_n_minus), V))
    return G_nn_n


def Green_in_n(G_in_n_minus, V, G_nn_n):  # n>=2
    G_in_n = np.dot(np.dot(G_in_n_minus, V), G_nn_n)
    return G_in_n


def Green_ni_n(G_nn_n, V, G_ni_n_minus): # n>=2
    G_ni_n = np.dot(np.dot(G_nn_n, V.transpose().conj()), G_ni_n_minus)
    return G_ni_n


def Green_ii_n(G_ii_n_minus, G_in_n_minus, V, G_nn_n, G_ni_n_minus):  # n>=i
    G_ii_n = G_ii_n_minus+np.dot(np.dot(np.dot(np.dot(G_in_n_minus, V), G_nn_n), V.transpose().conj()),G_ni_n_minus)
    return G_ii_n


if __name__ == '__main__':
    main()

参考资料:

[1] MacKinnon, "A. The calculation of transport properties and density of states of disordered solids",  Z. Physik B - Condensed Matter 59, 385–390 (1985).

1,495 次浏览

【说明:本站主要是个人的一些笔记和代码分享,内容可能会不定期修改。为了使全网显示的始终是最新版本,这里的文章未经同意请勿转载。引用请注明出处:https://www.guanjihuan.com

评论说明:
(1)在保留浏览器缓存的前提下,目前支持72小时自主修改或删除个人评论。如果自己无法修改或删除评论,可再次评论或联系我。如有发现广告留言,请勿点击链接,博主会不定期删除。
(2)评论支持Latex公式。把latexpage作为标签放在任何位置,评论中的公式可正常编译,示例:
$Latex formula$  [latexpage]

发表回复

您的电子邮箱地址不会被公开。 必填项已用*标注
